Axpert VM II	Axpert VM II 3000-24	Axpert VM II 5000-48
Rated Power	3000VA / 3000W	5000VA / 5000W
INPUT
Voltage	230 VAC	230 VAC
Selectable Voltage Range	170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances)		600
Frequency Range	50 Hz/60 Hz (Auto sensing)		80~550
OUTPUT
AC Voltage Regulation (Batt. Mode)	230VAC ± 5%	230VAC ± 5%
Surge Power	6000VA	10000VA
Efficiency (Peak)	90% ~ 93%	90% ~ 93%
Transfer Time	10 ms (For Personal Computers) ; 20 ms (For Home Appliances)		2
Waveform	Pure sine wave	Pure sine wave
BATTERY
Battery Voltage	24 VDC	48 VDC
Floating Charge Voltage	27 VDC	54 VDC
Overcharge Protection	32 VDC	63 VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Power	4000 W	4000 W
MPPT Range @Operating Voltage	120~450 VDC	120~450 VDC
Maximum PV Array Open Circuit Voltage	500 VDC	500 VDC
Maximum Solar Charge Current	80 A	80 A
Maximum AC Charge Current	60 A	60 A
Maximum Charge Current	80 A	80 A
PHYSICAL
Dimension,DxWxH (mm)	100 x 300 x 440	100 x 300 x 440
Net Weight (kgs)	9	10
ENVIRONMENT
Humidity	5% to 95% Relative Humidity (Non-condensing)		Integrated
Operating Temperature	-10°C to 50°C	-10°C to 50°C
Storage Temperature	-15°C - 60°C	-15°C - 60°C

	93.2% Response Rate
	1,400,000+ for 80 Transactions The supplier’s transactions conducted via Alibaba.com in the past 6 months.
	On-time delivery rate

Quantity(Pieces)	1 - 100	>100
Est. Time(days)	7	Negotiable

Quantity(Pieces)	1 - 100	>100
Est. Time(days)	7	To be negotiated

CE COQ RoHS Certificate Solar Power Inverter 3Kw 5Kw Pure Sine Wave Cotek Inverter
